Product Details:
|
| Marketing Type:: | Factory | After-sales Service Provided:: | 24 Hours After Sale |
|---|---|---|---|
| Material:: | Q345B | Packing:: | Can Provide Film, Wooden Box, Iron Frame Support |
| Applicable Industries:: | Basic Engineering Drilling | Product Name:: | CFA Long Spiral |
| Brand Name:: | Jin Yiyuan | Warranty Period:: | One Year |
| Place Of Origin:: | Tianjing, China | Specification: | 300mm～1000mm |
| Highlight: | Long Auger Bit with 16mm flight,16m Depth Long Auger Bit,16m Depth extra long auger drill bits |
||
100mm Auger Bit Extra Long Auger Bit
Product Advantage
Independently researched and developed alloys with high strength and good abrasion resistance;
Application :
Independently researched and developed world-class production equipment, advanced production technology,ensuring product quality stability.
Use:
Wide range of products, matching different working conditions.
| 1. Parameter | ||||
| Product Name | CFA Continuous Flight Auger | |||
| Material | Q345B | |||
| Technique | Forming, machining, heat treatment, welding | |||
| Coupling | Internal and external hexagonal joint | |||
| Diameter | 300mm～1000mm | |||
| Depth | 18m～21m | |||
| Model | Diameter (mm) | Flight Pitch (mm) | Flight Thickness (mm) | Length (m) |
| CFA300 | 300 | 250 | 16 | 2～6 |
| CFA400 | 400 | 340 | 16 | 2～6 |
| CFA500 | 500 | 400 | 16 | 2～6 |
| CFA600 | 600 | 500 | 20 | 2～6 |
| CFA700 | 700 | 500 | 20 | 2～6 |
| CFA800 | 800 | 500 | 20 | 2～6 |
| CFA900 | 900 | 500 | 20 | 2～6 |
| CFA1000 | 1000 | 500 | 20 | 2～6 |
| Customize: | ||||
| 1. Diameter: 300～1060mm | ||||
| 2. Depth: 16～25m | ||||
| 3. Flight thickness: 16~25mm | ||||
|
4. Coupling: Internal and external hexagonal joint or flange |
||||
