Product Details:
|
| Colour: | Customized | Dimensions M: | 3.54×2.25×2.80 |
|---|---|---|---|
| Liquid Handling Capacity M³/h: | 200 | Whole Machine Weight Kg: | 4800 |
| Total Power Kw: | 48 | Slag Screening Capacity T/h: | 25-80 |
| High Light: | 3.5m Length Mud Separator,80T/H Mud Separator,80T/H mud gas separator |
||
Mud Separator Mud Separation Equipment Mud Treatment Equipment
Introduction
The mud separation system is a necessary equipment for foundation construction. It is used for pile foundation projects using mud hole/tunnel wall support, rotary drilling rigs, and circular drilling techniques. The wall engineering and mud purification and recycling of the slurry wall project have the characteristics of reducing construction costs and improving construction efficiency. They are used for pile foundation projects using mud hole/tunnel wall support, rotary drilling rigs, and circular drilling technologies; underground continuous walls Mud purification and recovery for engineering and pipe jacking construction
Featurs
Separation process:
1. The slurry of soil particles with a feed pump enters the storage tank (3) through the coarse screen (7), and the solid separation exceeds 2 mm.
2. The fluid in the storage tank (3) is pumped into the cyclone separator (5), solids over 0.06mm are discharged from the dewatering screen (2), and the cleaned fluid is discharged through the overflow pipe (8) of the cyclone separator And enter the water storage tank (9).
3. Automatic water level control (10) maintains the water level in the water tank (3) to prevent the feed water pump (4) from running at no load or low load
Product parameters
| Liquid handling capacity m³/h | 200 |
| Dimensions m | 3.54×2.25×2.80 |
| Total power kw | 48 |
| Whole machine weight kg | 4800 |
| Slag screening capacity t/h | 25-80 |
| colour | customized |
Used in
The treatment system adopts a multi-stage treatment method according to the particle size range of solid particles in the mud, and can be applied to the treatment of various construction mud and river sludge.
FAQ
Q: What is the product range of Jinyiyuan Machinery?
A: Jinyiyuan Machinery is mainly engaged in the manufacturing and sales of various drill bits and drill pipes, as well as the import and export business of various drilling tools.
Q: How about the after-sales service of Jinyiyuan Machinery?
A: Jinyiyuan Machinery provides quality service after sale. All our products have a warranty period.
Q: Can I visit the factory?
A: We warmly welcome customers to visit our factory at any time. In addition to visiting the factory, we also warmly welcome customers or third parties to arrange pre-delivery inspections.
Q: What is the delivery time?
A: Usually, the delivery time is about 3-7 working days. The specific delivery time will be provided in each quotation.
