Product Details:
|
| Barrel Height(mm): | 1200 | Barrel Thickness (mm): | 16 |
|---|---|---|---|
| Thickness Of Bottom Plate: | 40 | Cutting Plate Thickness: | 50 |
| Number Of Teeth: | 11 | Weight(kg): | 870 |
| High Light: | Height 1200mm Rock Drilling Bucket,870KG Rock Drilling Bucket,Height 1200mm drilling bucket auger |
||
Double Bottom Double Open Rock Drill Bucket Cone Bucket
Introduction
Drill bits for rotary drilling rigs, soft soil drilling, cylinder high-strength manganese steel, alloy picks
Featurs
Double bottom double opening cutting disc. The cylinder body is a vertebral body, which is good for exhausting, better drilling and lifting. It is easy to pour the soil. The manufacturing material is high-strength manganese steel. The outer diameter of the drill bit is welded with high-strength wear-resistant welding wire to extend the service life. Replaceable alloy picks are arranged in staggered angles, easy to drill, fast and efficient. The opening and closing mechanism can be operated manually or mechanically. Detachable center quarter head. The corner shaft and central shaft are high-frequency hardened, wear-resistant and durable. Various specifications of drill bits can be customized according to the parameters provided by customers.
Product parameters
| Serial number | Specification | Bucket height (mm) | Barrel thickness (mm) | Thickness of bottom plate | Cutting plate thickness | Number of teeth | Weight (kg) |
| 1 | φ600 | 1200 | 16 | 40 | 50 | 11 | 870 |
| 2 | φ800 | 1200 | 16 | 40 | 50 | 14 | 1151 |
| 3 | φ1000 | 1200 | 16 | 40 | 50 | 20 | 1382 |
| 4 | φ1200 | 1200 | 16 | 40 | 50 | 26 | 1778 |
| 5 | φ1500 | 1200 | 16 | 40 | 50 | 28 | 2295 |
| 6 | φ1800 | 1200 | 16 | 50 | 50 | 32 | 3042 |
| 7 | φ2000 | 800 | 20 | 50 | 50 | 36 | 3850 |
| 8 | φ2200 | 800 | 20 | 50 | 50 | 38 | 4670 |
| 9 | φ2500 | 800 | 20 | 40 box type | 40 box type | 40 | 6060 |
|
Connection square head 200mm |
|||||||
Used in
Suitable for drilling in rock layers or harder pebble layers
FAQ
Q: What is the product range of Jinyiyuan Machinery?
A: Jinyiyuan Machinery is mainly engaged in the manufacturing and sales of various drill bits and drill pipes, as well as the import and export business of various drilling tools.
Q: How about the after-sales service of Jinyiyuan Machinery?
A: Jinyiyuan Machinery provides quality service after sale. All our products have a warranty period.
Q: Can I visit the factory?
A: We warmly welcome customers to visit our factory at any time. In addition to visiting the factory, we also warmly welcome customers or third parties to arrange pre-delivery inspections.
Q: What is the delivery time?
A: Usually, the delivery time is about 3-7 working days. The specific delivery time will be provided in each quotation.
